Export Specifications
| Motherboard Series | Intel chipset,COLORFUL series |
| Chipset | Intel H81 |
| Processor | support Intel LGA1150 Haswell processors |
| Memory | Dual-Channel 1600/1333/1066MHz support,Offer 2 DIMM slots |
| Graphics Support | 1 PCI-Express 2.0 x16 slot |
| SATA Ports | 2*SATA2.0&2*SATA3.0 ports |
| Board I/O | 2 *PS/2 Mouse/ Keyboard port，1 x LAN(RJ45) port，4x USB 2.0/1.1 ports，6-Channel Audio I/O,1 VGA+DVI+HDMI Port,2x USB connectors support additional 4 USB 2.0/1.1 ports,1x USB3.0 connectors support additional 2 USB 3.0 ports,1x 3-pin Spdif in/out connector |
| Expansion Slots | 5 PCI-Express 2.0 x1 slots |
| BIOS | 64M UEFI |
| Hardware Monitor | CPU Fan speed Controlled，SYSTEM Fan speed Monitoring,CPU Temperature Monitoring，System Temperature Monitoring，and Voltage monitoring |
| LAN | Realtek RTL8111E 1000M LAN,Provides 10/100/1000Mb Ethernet |
| Audio | 6-channel High Definition Audio Codec integrated,HD audio |
| Configuration | 185*295MM,ATX |
1、Pictures for reference only, subject to our available products. Product information may vary slightly, depending on your country or region. Please contact local dealers for latest product specification.
2、The color of product may differ from the actual product depending on the camera angle and screen settings . We will try our best to provide the accurate and complete data online. We reserve the right to modify the page information at any time without prior notice.
3、Product information are for reference only and subject to change at any time. Please contact local dealers for latest product specification.
4、We may update our product and software at any time. Please contact local dealers for latest information.
5、For all above product name and related trademark, we reserved the right of final interpretation.
-
-
